AIM-75S

Industrial Grade Tablet | 8" FHD 400 nits | IP65

Производител: Advantech

Display: 8" FHD 400 nits
Weight: 0.68 kg
Dimensions (W, D, H): 230 x 22 x 146 mm
Resistance: IP65, 1.2 m drop
Operating Temperature: From –10°C to +50°C
RAM: 4 GB (optional 8 GB)
Storage: 64 GB eMMC, Micro SD up to 2 TB
System: Android
Warranty: 24 months

Изчерпан

Безплатна доставка

Promocja cenowa na model HDR-15-5

Продукт, предназначен само за професионална употреба

Описание
Basic parameters
Техническа спецификация
Download
Препоръчани продукти

AIM-75S

Описание

AIM-75S – 8" Industrial Grade Tablet

Power and Responsiveness
Built on the Qualcomm platform and Android Enterprise Recommended, the AIM-75S delivers smooth performance for inspection, medical, and industrial applications, along with consistent security updates.

Display Without Compromise
The 8" panel (1920 × 1200) offers 400 nits of brightness and is protected by Gorilla Glass 3. It supports stylus and glove input, ensuring comfortable use in any environment.

Engineered for Tough Environments

IP65 – sealed against dust and low-pressure water jets
Drop-tested – survives 1.2 m falls onto concrete

Mobility and Connectivity
LTE, Wi-Fi, Bluetooth, NFC, and GPS ensure reliable field connectivity. Docking options (desk, vehicle, multi-bay) help reduce downtime and keep the device ready to go.

Specialized Ports
The modular AIM connector supports 1D/2D barcode scanners, LAN+COM modules, or UHF RFID — no cables or screws required.

Data Security
Google Play Protect and FBE encryption safeguard sensitive data. Remote lock and wipe are available via DeviceOn/iService platform.

Warranty
Comes with a standard 24-month warranty, extendable upon request.

Basic parameters

Processor	Qualcomm platform, Android Enterprise Recommended	Water & Dust Resistance	IP65
Display	8" FHD (1920 × 1200), 400 nits, Gorilla Glass	Connectivity	Wi-Fi, Bluetooth, NFC, GPS, LTE
Battery	Removable, docking station support	Certifications	Google Play Protect, Android security updates
Storage	64 GB eMMC, Micro SD up to 2 TB	Accessories	Desk, vehicle, multi-bay docking stations
Drop Resistance	1.2 m onto concrete	Customization	1D/2D scanner, LAN+COM, UHF RFID (modular)

Техническа спецификация

Key Specifications

System	Android 10 or Android 12 (Android Enterprise Recommended) Processor: Qualcomm® Snapdragon™ 660, octa-core 2.2 GHz Memory: 4 GB LPDDR4x RAM Storage: 64 GB eMMC - expandable via microSD to 2 TB
Wireless Communication	Wi-Fi 5 (IEEE 802.11 a/b/g/n/ac/k/v/r) & Bluetooth® 5.0 NFC 13.56 MHz (ISO 15693 / 14443 A/B, Felica) Optional LTE • optional Google Mobile Services (GMS)
Display	8″ IPS LCD, WUXGA 1920 × 1200 Brightness: 400 cd/m² 10-point P-CAP touch, Corning® Gorilla® Glass 3
I/O Interface	USB Type-C 3.0 × 1 • 3.5 mm audio combo jack × 1 SIM card slot × 1 • microSD slot × 1 AIM 14-pin pogo connector (USB 2.0, UART, 5 V/1 A)
Hardware Buttons	Power • Volume ± • 1× programmable key
Cameras	Front: 5 MP fixed-focus Rear: 8 MP auto-focus with LED flash
Sensors	Ambient light • Compass • G-sensor • Gyroscope
Power System	Swappable battery – 4 900 mAh / 18.6 Wh, up to 12 h runtime, < 3 h charge Input: USB-C 5 V/3 A, 9 V/2 A • Dock pogo 9 V/2 A
Durability	IP65 sealing • SAE J1455 vibration / shock Drop-tested 1.2 m (4 ft) onto plywood Operating: –10 °C … +50 °C (charging 0 … 40 °C) Storage: –20 °C … +60 °C Humidity: 10 – 90 % (oper.) / 10 – 95 % (stor.) non-condensing
Dimensions & Weight	240 × 142 × 14.5 mm 600 g
Certifications	FCC • PTCRB • CE • CB • UL • TELEC • BSMI • NCC • CCC • SRRC • RCM • IC
