GigaEter Duo 19 5GHz WideBand
Broad-band double polarizated antenna with gain of 19 dBi
- broad-band double polarizated antenn
- Frequency range: 4,9 - 6,0 GHz
- Gain: 19 dBi
- Connector: 2xN/Female
- MIMO 2x2
Висока цена? Влезте в профила си и купете на по-ниска
Поръчайте до 12:00 и ще бъде изпратен в рамките на деня
Безплатна доставка от €100
Promocja cenowa na model HDR-15-5
Продукт, предназначен само за професионална употреба
GigaEter Duo 19 5GHz WideBand
Модели
-
Модел Наличност Гаранция Wishlist Вашата ценаВашата цена Items Quantity ДобавиGigaEter Duo 19 5GHz WideBand (3200)directional 5 GHz MIMO 19 dBiНаличен на складГаранционен срок: €50.00€61.50Влезте, за да проверите цената си GigaEter Duo 19 5GHz WideBand (3200)directional 5 GHz MIMO 19 dBiНаличност:Наличен на складНетна цена:€50.00
Описание
PAN 5-19HV WB is broad-band double polarizated antenna with gain of 19 dBi, it's predicted for operation at the frequency of 4900 - 6000 MHz. Antenna is designed for
dual links and 2x2 MIMO links at the standard of 802.11n on medium distances.
Separation between connectors is 37dB. This antenna distinquish itself with wide beamwidth, from 4900 MHz up to 6000MHz. Medium antenna gain allows for realize wireless links on
medium distances. Narrow radiation beam allows to avoid interferences and noise level even on short distances.
Antenna has DC ground what prevents devices connected with antennas.
Solid bracket and U-Bolt come with antenna, they ensure for stability and resistance for wind and allows for antenna slope (advantage with making precise links).
Техническа спецификация
| Antenna type | directional |
| Frequency range | 4,9 - 6,0 GHz |
| Gain for vertical polarization | 19 dBi (min) 5,25-5,875 GHz 17.5dBi (min) 4,9-5,25 GHz; 5,875 - 6,0 GHz dBi |
| Gain for horizontal polarization | 19 dBi (min) 5,25 - 5,875 GHz 17.5dBi (min) 4,9 - 5,25 GHz; 5,875 - 6,0 GHz dBi |
| Polarization | vertical + horizontal |
| Back ratio | (max) -30 dB |
| Separation between connectors | > 37 dB |
| Vertical beam width | 18 ° for -3dB |
| Horizontal beam width | 18 ° for -3dB |
| VSWR | 1,5:1 (typ) 1,9 : 1 (max) |
| Impedance | 50 Ohm |
| Connector | 2 x N/Female |
| Maksymalna moc | 6 W |
| Wind load | 56 m/s |
| The diameter of the mast / pole | 38 - 51 mm |
| Dimensions | 390 x 430 mm |
| Package dimension | 49/41/9 cm |
| Total weight | 1654 g |
| Weight with mounting | 1250 g |
| Weight without mounting | 850 g |
| Warranty | 36 months |
