ELMATIC ETA 1221-WT

Fanless DIR-rail BOX PC, Intel Atom x6413E, 8GB RAM, 128GB SSD, Windows 11 IoT

  • 2x 2.5 GbE LAN
  • 2x USB3.2, 2x USB2.0
  • 2 x RS-232/422/485 (default RS-232)
  • 1x HDMI, 1x DisplayPort
  • 8-bit Programmable DIO
  • No power supply by default (see accessories)
Цена от 943,00 € нетна цена

Висока цена? Влезте в профила си и купете на по-ниска

Наличен на склад

Поръчайте до 12:00 и ще бъде изпратен в рамките на деня

Безплатна доставка от €100

Вижте 1 модел

Promocja cenowa na model HDR-15-5

Продукт, предназначен само за професионална употреба
ELMATIC ETA 1221-WT

ELMATIC ETA 1221-WT

Модели

Аксесоари

Описание

The ELMATIC ETA 1221-WT is a fanless Box PC designed for DIN rail mounting, equipped with an Intel Atom x6413E processor, 8 GB of RAM, and 128 GB of built-in SSD storage. The device offers two 2.5 GbE LAN ports, two USB 3.2 ports, two USB 2.0 ports, two RS-232/422/485 serial ports (RS-232 by default), one HDMI output, one DisplayPort output, and 8-bit programmable DIO. The operating temperature range is from -40°C to 60°C. Windows 11 IoT is included in the package.

Техническа спецификация

Model
Model ELMATIC ETA 1221-WT
CPU
CPU Intel Atom x6413E
Memory
Memory Built-in 8 GB SODDR4
Storage
Slot 2,5" HDD Built-in 128GB SSD
Slot mSATA -
Expansions
Slot M.2 1 x M2. 2230 E key
1 x M.2 2280 B key with nano SIM holder *
(* SIM holder and M.2 slot are hardware interfaces for wireless communication integration only. System level RF certification is not available)
Slot miniPCIe 1 x Full-size
I/O
DisplayPort 1
HDMI 1
Audio Mic in, Line out
Gigabit Ethernet 2 x 2.5 GbE LAN
USB 3.2 2
USB 2.0 2
Serial Ports 2 x RS-232/422/485 (default RS-232)
GPIO 8-bit Programmable DIO
CANbus -
Operating System
Operating System Windows 11 IoT LTSC included
Environment
Working temperature -40 ~ 60°C
