Производител: MEAN WELL
- input voltage 88-264VAC, 124-370VDC
- protections: short circuit, overvoltage and overload protection
- PFC function
- protection against battery discharge
- ability to adjust the output voltage in the range of +/- 10%
- cooling with open air circulation (70% of power)
- 100% power with external fan cooling
- working temperature from -10 ~ + 60 ° C
- compliance with many standards and certificates
- possibility of installation on a DIN rail (using adapters)
- 2 years warranty
Discounted prices and exact stock levels are visible after logging in to the e-shop.
Цена от 60,50 € без данък
High price? Log in and buy cheaper
In stock
Направете поръчката до 12:00 часа, пратката ще бъде изпратена на същия ден
Безплатна доставка от €100
Promocja cenowa na model HDR-15-5
Продукт, предназначен само за професионална употреба
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAD-155Apower supply 155W 13.8V 11.5A, 13.3V 0.5AIn stockWarranty: 60,50 €74,42 €Login to check your price AD-155Apower supply 155W 13.8V 11.5A, 13.3V 0.5AAvailability:In stockNet price:60,50 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAD-155Bpower supply 155W 27.6V 5.5A, 27.1V 0.5AIn stockWarranty: 60,50 €74,42 €Login to check your price AD-155Bpower supply 155W 27.6V 5.5A, 27.1V 0.5AAvailability:In stockNet price:60,50 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddAD-155Cpower supply 155W 54V 2.7A, 53.5V 0.5AIn stockWarranty: 60,50 €74,42 €Login to check your price AD-155Cpower supply 155W 54V 2.7A, 53.5V 0.5AAvailability:In stockNet price:60,50 €
Description
AD, ADS, ADD series power supplies are designed to work in monitoring systems, access control, alarm systems, etc. AD and ADD models with an external battery can work as UPS power supplies. Discharge protection avoids over-discharging the battery.
Technical Specification
- AD-155: 152~157W DETAILS
Model Output Tolerance Ripple & noise Efficiency Max power Dimension AD-155A 13.8V, 0~11.5A
13.3V, 0~0.5A+/-2%
(charging)150mV 80% 152W 199x110x50mm AD-155B 27.6V, 0~5.5A
27.1V, 0~0.5A+/-1%
(charging)150mV 84% 152W 199x110x50mm AD-155C 54.0V, 0~2.7A
53.5V, 0~0.5A+/-1%
(charging)240mV 84% 157W 199x110x50mm
