SPOL-01
DC / DC converter, adjustable, PCB module type
- input voltage range 3 ~ 14VDC
- high efficiency up to 90%
- output voltage adjustment
- short circuit protection
- remote on / off
- cooling in open air circulation
- working temperature -40 ~ + 82 ° C
- low cost, high reliability
- 3-year warranty
Discounted prices and exact stock levels are visible after logging in to the e-shop.
Цена от €3.80 нетна цена
Висока цена? Влезте в профила си и купете на по-ниска
Изчерпан
Безплатна доставка от €100
Promocja cenowa na model HDR-15-5
Продукт, предназначен само за професионална употреба
Модели
-
Модел Наличност Гаранция Wishlist Вашата ценаВашата цена Items Quantity ДобавиSPOL-01DC/DC converter 5.5W 3~14V/5V 1AИзчерпан Гаранционен срок: €3.80€4.67Влезте, за да проверите цената си SPOL-01DC/DC converter 5.5W 3~14V/5V 1AНаличност: ИзчерпанНетна цена:€3.80
Описание
MEAN WELL SPOL-01 is a dc / dc converter in the form of a PCB module designed for soldering. Its characteristic features are small dimensions, high efficiency and the ability to remotely regulate the output voltage. High quality, reliability, durability and long service life are the basic advantages of MEAN WELL inverters.
Техническа спецификация
- SPOL-01: DC / DC converter, adjustable, PCB module type SPECIFICATION
| Model | Input | Output | Ripple&Noise | Efficiency | Dimensions |
| SPOL-01 | 3~14V | 5.5V, max.1A | 40mV | 90% | 12.4x12.4x4.0mm |
| 5V, max.1A | 40mV | 89.5% | 12.4x12.4x4.0mm | ||
| 3.3V, max.1A | 40mV | 86% | 12.4x12.4x4.0mm | ||
| 2.5V, max.1A | 40mV | 83% | 12.4x12.4x4.0mm | ||
| 1.8V, max.1A | 40mV | 79% | 12.4x12.4x4.0mm | ||
| 1.5V, max.1A | 40mV | 75% | 12.4x12.4x4.0mm | ||
| 1.2, max.1A | 40mV | 71% | 12.4x12.4x4.0mm | ||
| 0.9V, max.1A | 40mV | 67% | 12.4x12.4x4.0mm |
