Производител: MEAN WELL
- SMD housing with standard pins
- permissible operating temperatures from -40 to + 90 ° C
- high efficiency up to 84%
- short circuit protection
- short-circuit strength 1.5kVDC
- 3-year warranty
Discounted prices and exact stock levels are visible after logging in to the e-shop.
Цена от 3,80 € без данък
High price? Log in and buy cheaper
Product out of stock
Безплатна доставка от €100
Promocja cenowa na model HDR-15-5
Продукт, предназначен само за професионална употреба
Models
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01L-05DC/DC module 1W 5V±10%/ 5V 0.2AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01L-05DC/DC module 1W 5V±10%/ 5V 0.2AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01L-09DC/DC module 1W 5V±10%/ 9V 0.111AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01L-09DC/DC module 1W 5V±10%/ 9V 0.111AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01L-12DC/DC module 1W 5V±10%/ 12V 0.084AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01L-12DC/DC module 1W 5V±10%/ 12V 0.084AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01L-15DC/DC module 1W 5V±10%/ 15V 0.067AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01L-15DC/DC module 1W 5V±10%/ 15V 0.067AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01M-05DC/DC module 1W 12V±10%/ 5V 0.2AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01M-05DC/DC module 1W 12V±10%/ 5V 0.2AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01M-09DC/DC module 1W 12V±10%/ 9V 0.111AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01M-09DC/DC module 1W 12V±10%/ 9V 0.111AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01M-12DC/DC module 1W 12V±10%/ 12V 0.084AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01M-12DC/DC module 1W 12V±10%/ 12V 0.084AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01M-15DC/DC module 1W 12V±10%/ 15V 0.067AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01M-15DC/DC module 1W 12V±10%/ 15V 0.067AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01N-05DC/DC module 1W 24V±10%/ 5V 0.2AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01N-05DC/DC module 1W 24V±10%/ 5V 0.2AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01N-09DC/DC module 1W 24V±10%/ 9V 0.111AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01N-09DC/DC module 1W 24V±10%/ 9V 0.111AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01N-12DC/DC module 1W 24V±10%/ 12V 0.084AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01N-12DC/DC module 1W 24V±10%/ 12V 0.084AAvailability: Out of stockNet price:3,80 € -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddSBTN01N-15DC/DC module 1W 24V±10%/ 15V 0.067AOut of stock Warranty: 3,80 €4,67 €Login to check your price SBTN01N-15DC/DC module 1W 24V±10%/ 15V 0.067AAvailability: Out of stockNet price:3,80 €
Description
A series of DC / DC converters in SMD execution. All models are available with an input voltage of 4.5 ~ 5.5VDC, 10.8 ~ 13.2VDC or 21.6 ~ 26.4VDC. Depending on the model, the output voltages are 5/9/12 / 15VDC. The converters have a wide range of operating temperatures, high efficiency and meet the EMC standards set out in the EN / EN55032 standard. All models are covered by a 3-year warranty.
Technical Specification
- SBTN01: DC / DC converter in SMD 1W housing SPECIFICATION
| Model | Input | Output | Ripple&Noise | Dimensions |
| SBTN01L-05 | 4.5~5.5VDC | 5VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01L-09 | 4.5~5.5VDC | 9VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01L-12 | 4.5~5.5VDC | 12VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01L-15 | 4.5~5.5VDC | 15VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01M-05 | 10.8~13.2VDC | 5VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01M-09 | 10.8~13.2VDC | 9VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01M-12 | 10.8~13.2VDC | 12VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01M-15 | 10.8~13.2VDC | 15VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01N-05 | 21.6~26.4VDC | 5VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01N-09 | 21.6~26.4VDC | 9VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01N-12 | 21.6~26.4VDC | 12VDC | 75mVp-p | 12.9x10.9x7.1mm |
| SBTN01N-15 | 21.6~26.4VDC | 15VDC | 75mVp-p | 12.9x10.9x7.1mm |
