CG480-S5063
4U Server grade IPC, Dual Intel Xeon 6500/6700 series., NVIDIA MGX architecture, IPMI 2.0 and DMTF Redfish API
- 4U (NVIDIA MGX architecture )
- Dual Intel Xeon 6500/6700 series processors, TDP up to 350W
- (32) DDR5 RDIMM, 8 channels per CPU(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC)
- (20) Front hot-swap E1.S PCIe 5.0 x4 NVMe drive bays
- (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
- Max (13) PCIe 5.0 x16 expansion slots, supporting up to (8) NVIDIA H200 NVL PCIe GPU cards
- (2) 10GBase-T Ethernet ports with Intel X710-AT2 (NCSI supported)
- (1) 1000Base-T Dedicated Server Management port with: ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support Dual BIOS & BMC TPM2.0 on board
- Hardware Root of Trust is supported as optional
Изчерпан
Безплатна доставка от €100
Promocja cenowa na model HDR-15-5
Продукт, предназначен само за професионална употреба
CG480-S5063
Описание
Application
- Training, Fine Tuning
- LLM Inference
- NVIDIA Omniverse
Техническа спецификация
| Form Factor | 4U |
| Dimensions | 438.5mm(17.2")W x175mm(6.88")H x800mm(31.4")D |
| Processor | Dual Intel Xeon 6700E- series, 6500P-series and 6700P-series processors, TDP up to 350W |
| Socket | (2) LGA4710 (Socket E2) |
| Memory | (32) DDR5 DIMM Slots, 8 channels per CPU(2DPC), RDIMM/RDIMM-3DS/MRDIMM - Max. Frequency: RDIMM: 6400MT/s(1DPC), 5200MT/s(2DPC) MRDIMM: 8000MT/s(only support 1DPC) - Max. Capacity per DIMM: 256GB(RDIMM), 64GB(MRDIMM) |
| Drive Bays | (20) Front hot-swap E1.S PCIe 5.0 x4 NVMe drive bays (10 from CPU0, 10 from CPU1) |
| Internal Storage | (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports (CPU0) |
| Expansion Slots | (8) PCIe 5.0 x16 FHFL double wide slots (through PCIe switch) (4) PCIe 5.0 x16 FHFL single wide slots (through PCIe switch) (1) PCIe 5.0 x16 FHFL single wide slot (from CPU0) |
| Networking | (2) 10GBase-T Ethernet Ports with Intel® X710-AT2 (NCSI supported) |
| RAID | NVMe RAID 0/1/5/10 support (Intel VROC RAID key required) |
| Front I/O | (20) Hot-swap E1.S drive bays |
| Rear I/O | (1) 1000Base-T Dedicated Server Management port (2) 10GBase-T Ethernet ports (1) USB 3.0/2.0 Type-A port (1) Mini Display port (1) Power LED button (1) UID LED button |
| Security | Chassis Intrusion On-board TPM2.0 Hardware Root of Trust - Microchip CEC1736 supported (optional) |
| Server Management | (1) 1000Base-T Dedicated Server Management port ASPEED AST2600 with AMI MegaRAC based firmware supporting IPMI 2.0 and DMTF Redfish API Dual BIOS and dual BMC eMMC for local BMC storage media |
| Environment | System Operating Temperature: 0°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -20°C ~ 70°C (-4°F to 158°F) Non-operating Relative Humidity: 5% to 85% (non-condensing) |
| Power Supply | (3+1) Redundant 3200W CRPS 80 PLUS Titanium Dimensions (WxHxL): 73.5 x 40 x 185 mm Rating: AC Input: 100-127Vac, 16A, 50-60Hz Output: Max 1200W, DC +12V/106.6A, +12Vsb/3A AC Input: 200-219Vac, 16A, 50-60Hz Output: Max 3000W, DC +12V/246A, +12Vsb/3A AC Input: 220-240Vac, 16A, 50-60Hz Output: Max 3200W, DC +12V/262.3A, +12Vsb/3A DC Input: 240V, 16A Output: Max 3200W *C19 power cords are required and will be offered as optional accessories. |
| Cooling | (2) Air cooling modules for max. 350W CPU (10) 8080 Hot-swap system fans |
| Certification | CE, FCC (Class A) |
