Optics

• Display resolution: nHD color display
• Display type: OLED
• Aspect ratio: 16:9
• Field of view (diagonal): 16.8°, equivalent to a 5 in. mobile device screen seen at 17 inches
• Brightness: > 2000 nits
• Contrast: > 10,000:1
• 24-bit color with true black
• Supports left or right eye use

Certifications

• IP67 Rated (Longevity Series)
• Drop safe to 2 meters

Mounting options

• Vuzix M-Series Rail Eyeglass frames without lens (standard)
• Weighs less than 3 oz.
• Eyeglass frames with lens
• Safety glasses
• Hard hat mount
• Headband mount
• Peltor headphone mount

Controls

• 3 control buttons
• Voice control is customizable and supports multiple languages
• 2 axis touchpad with multi-finger support

Audio

• Integrated speaker (up to 97db output)
• Triple noise-canceling microphones

Camera

• Up to 12.8-megapixel stills
• Up to 4k30 video
• Improved auto-focus (PDAF)
• Improved optical image stabilization
• LED flash/scene illumination
• Barcode scanning

Connectivity

• USB 3.1 Gen 2 on USB Type-C

Head Tracking

• 3-degree of freedom head tracking
• 3 axis gyro
• 3 axis accelerometer
• 3 axis mag/integrated compass

GPS

• GPS / GLONASS

Environment

• Operating temperature -20ºC to 45ºC/-4ºF to 113ºF
• Operating humidity 0-95% RH
• Storage temperature 10-45ºC
• Storage humidity 0-95% RH
