NOTE: DR-100 series is phased-out by the manufacturer and are available while stock lasts. As a replacement we suggest HDR-100 series. |
Производител: MEAN WELL
- Universal AC input/Full range
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15
- Isolation class II
- LED indicator for power on
- No load power consumption<1W
- 100% full load burn-in test
Product out of stock
Безплатна доставка от €100
Promocja cenowa na model HDR-15-5
Продукт, предназначен само за професионална употреба
Accessories
-
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddИндустриално захранване за DIN шина: HDR-100-12, HDR-100-15, HDR-100-24, HDR-100-48, HDR-100-12N, HDR-100-15N, HDR-100-24N, HDR-100-48NOut of stock Warranty: Цена от 26,00 € без данък0Login to check your price Индустриално захранване за DIN шина: HDR-100-12, HDR-100-15, HDR-100-24, HDR-100-48, HDR-100-12N, HDR-100-15N, HDR-100-24N, HDR-100-48NAvailability: Out of stockNet price:Цена от 26,00 € без данък -
Model Availability Warranty Wishlist Your PriceYour Price Items Quantity AddIndustrial DIN rail power supply: NDR-120-12, NDR-120-24, NDR-120-48Out of stock Warranty: Цена от 26,40 € без данък0Login to check your price Industrial DIN rail power supply: NDR-120-12, NDR-120-24, NDR-120-48Availability: Out of stockNet price:Цена от 26,40 € без данък
Description
- Universal AC input/Full range
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15
- Isolation class II
- LED indicator for power on
- No load power consumption<1W
- 100% full load burn-in test
Available models:
- 12V: DR-100-12
- 15V: DR-100-15
- 24V: DR-100-24
Technical Specification
DR-100: 90-100.8W DETAILS
| Model | Output | Tolerance | Ripple & noise | Efficiency | Dimension |
| DR-100-12 | 12V, 0~7.5A | +/-2% | 120mV | 87% | 100x93x56mm |
| DR-100-15 | 15V, 0~6.5A | +/-1% | 120mV | 87% | 100x93x56mm |
| DR-100-24 | 24V, 0~4.2A | +/-1% | 150mV | 89% | 100x93x56mm |
